GENERAL

• Packaged Quantity
  1
• Platform Technology
  Intel Centrino
• Embedded Security
  Trusted Platform Module (TPM) Security Chip
• Operating System
  Microsoft Windows XP Professional
• Notebook type
  Ultraportable (Under 4 lbs.)
• Wireless capabilities
  IEEE 802.11b, IEEE 802.11g
• Manufacturer
  Lenovo

PROCESSOR / CHIPSET

• CPU
  Intel Pentium M 1.7 GHz
• Cache
  L2 - 1 MB
• Data Bus Speed
  400 MHz
• Chipset Type
  Intel 855PM
• Features
  Enhanced SpeedStep technology

STORAGE

• Type
  none
• Type
  portable

RAM

• Memory Speed
  266 MHz
• Memory Specification Compliance
  PC2700
• Configuration Features
  1 x 256 MB

MEMORY

• Max Supported Size
  2 GB
• Technology
  DDR SDRAM
• Speed
  266 MHz / PC2700
• Form Factor
  SO-DIMM 200-pin
• Slots Qty
  2
• Empty Slots
  1

DISPLAY

• Resolution
  1024 x 768 ( XGA )
• Widescreen Display
  No
• Color Support
  24-bit (16.7 million colors)

ENVIRONMENTAL PARAMETERS

• Environmental standards
  EPA Energy Star
• Humidity Range Operating
  8 - 95%
• Max Altitude Operating
  9840 ft
• Sound Emission
  41 dB

HARD DRIVE

• Spindle Speed
  4200 rpm

AUDIO & VIDEO

• Graphics Processor
  AGP 4x - ATI Mobility Radeon - 16 MB DDR SDRAM
• Sound
  Speaker , microphone

INPUT

• Type
  TrackPoint, keyboard

COMMUNICATIONS

• Wireless Protocol
  802.11a/b/g
• Wired Protocol
  Gigabit Ethernet

FLOPPY DRIVE

• Type
  none

MODEM

• Protocols & Specifications
  ITU V.92

BATTERY

• Technology
  6-cell lithium ion
• Installed Qty
  1
• Max Supported Qty
  2
• Capacity
  4400 mAh
• Run Time (Up To)
  5.5 sec
• Cells
  6-cell
• Technology
  lithium ion

AC ADAPTER

• Input
  AC 120/230 V ( 50/60 Hz )
• Output
  56 Watt

CONNECTIONS & EXPANSION

• Slots
  2 x memory ( 1 free )
  1 x CardBus ( 1 free )
• Interfaces
  2 x USB 2.0 - 4 pin USB Type A
  1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
  1 x infrared - IrDA
  1 x modem - phone line - RJ-11
  1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45
  1 x parallel - IEEE 1284 (EPP/ECP) - 25 pin D-Sub (DB-25)
  1 x IEEE 1394 (FireWire) - 4 pin FireWire
  1 x microphone - input - mini-phone 3.5 mm
  1 x audio - line-in - mini-phone stereo 3.5 mm
  1 x headphones - output - mini-phone stereo 3.5 mm
  1 x docking / port replicator

NETWORKING

• Max Transfer Rate
  56 Kbps
• Data Link Protocol
  Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g
• Remote Management Protocol
  CIM, DMI 2.0
• Wireless LAN Supported
  Yes

MISCELLANEOUS

• Integrated Options
  ThinkLight
• Security
  Trusted Platform Module (TPM) Security Chip
• Features
  ThinkVantage Embedded Security Subsystem 2.0, administrator password, asset ID, hard drive password, power-on password, security lock slot (cable lock sold separately)
• Compliant Standards
  ACPI 1.0b, Plug and Play, SASO, UL 1950, VCCI-II, cUL, ACPI 2.0, BSMI, CCIB, FCC Class B certified, GOST, MPR II, MPR III, NOM

MONITOR

• Diagonal Size
  12.1 in
• Color Support
  24-bit (16.7 million colors)

SOFTWARE

• Microsoft Office Preloaded
  Includes a pre-loaded image of select Microsoft Office 2010 suites. Purchase an Office 2010 Product Key Card or disc to activate preloaded software on this PC.

GRAPHICS CONTROLLER

• Interface Type
  AGP 4x

DIMENSIONS & WEIGHT

• Width
  10.7 in
• Depth
  8.8 in
• Height
  1.2 in

AUDIO OUTPUT

• Compliant Standards
  AC '97, DirectSound, SoundMAX

MANUFACTURER WARRANTY

• Type
  3 years warranty

ENVIRONMENTAL STANDARDS

• ENERGY STAR Qualified
  Yes

PHYSICAL CHARACTERISTICS

• Weight
  3.53 lbs

POWER

• Type
  power adapter
• Min Operating Temperature
  41 °F
• Max Operating Temperature
  95 °F

OPERATING SYSTEM / SOFTWARE

• OS Provided: Type
  Microsoft Windows XP Professional
• Type
  Access IBM, Adobe Acrobat Reader, Norton AntiVirus 2003 (OEM) , PC Doctor, ThinkVantage Access Connections, ThinkVantage Rapid Restore Ultra
